Mini backlight - WH5436RGB
VDD= 3V~5V
Matrix Structure
-Current Channel :9
-MUX:4
Sink Current Capability
-Max.12mA per channel
-Global Brightness control (GBc): 4-Bit Control
-Local Brightness Control (LBC):8-Bit Control for each zone
-Individual Zone PWM & Dc Control
- Model Number: WH5436RGB
- Data Sheet:
- Quantity:
- - +
Product Specification
FEATURE：
VDD= 3V~5V
Matrix Structure
-Current Channel :9
-MUX:4
Sink Current Capability
-Max.12mA per channel
-Global Brightness control (GBc): 4-Bit Control
-Local Brightness Control (LBC):8-Bit Control for each zone
-Individual Zone PWM & Dc Control
PWM Grayscale Depth
-Max.16-Bit
-Fixed PwM Clock= 32MHz
12c-Wire lnterface
.Up to 1MHz Speed
Single Fault Protection
-LED Open
-LED Short
-Themal Shutdown w/40℃ hysteresis
-UVLO
Anti.-Ghosting
PWM Output Alignment
-Head & Centre alignment
