Single-channel Gas Alarm Control Panel - KB2160
Power supply:
Main power: AC 220V +/-33V 50Hz +/-5Hz
Battery backup: DC 24V +/-3V
Power consumption: <=10W
Power output: DC24V+/-6V <=5W
Detector connected: 4-20mA analog signal
Ingress protection: IP54
- Model Number: KB2160
- Quantity:
- - +
Product Specification
single-channel control panel
Specifications:
Power supply:
Main power: AC 220V +/-33V 50Hz +/-5Hz
Battery backup: DC 24V +/-3V
Power consumption: <=10W
Power output: DC24V+/-6V <=5W
Detector connected: 4-20mA analog signal
Ingress protection: IP54
Working temperature:-10oC~50oC
Working humidity: <=95%RH
Indication methods:
LED lights
LCD screen
Audible and visual signals
Alarming methods: Audible and visual signals
Relay output: Free contact (capacity 2A/AC220V)
